Bletchley
GUCC Fleet No.
119
Class
Town
Original Type:
Motor
Known As
Large Woolwich
Date Built
9.12.36
Hull Construction
Steel
Registered
BREN 613
Intended Paring
224
History
sc 2/00 waterways world 3/00. paired with ARGUS 10/00photos
