Crux
GUCC Fleet No.
265
Class
Star
Original Type:
Butty
Known As
Small Woolwich
Date Built
24.7.35
Hull Construction
Iron Composite
Registered
BREN 495
Intended Paring
23
History
conv 9/91 new blue and yellow paint job at Dadfords 7/01
