Pictor
GUCC Fleet No.
332
Class
Star
Original Type:
Butty
Known As
Small Woolwich
Date Built
24.7.35
Hull Construction
Iron Composite
Registered
BREN 507
Intended Paring
70
History
PICTORÂ uncon. s.c.
